KVM over IP Switch - 1 Port, VGA, Up to 1920 x 1080@60Hz


Style: KVM over IP Switch - 1 Port / VGA
Price:
Sale price$450.00

Description

Product ID: TR300IPK

Description:

The TR300IPK is a IP-based KVM control units with enterprise level security which allow 1 local and 4 remote operators to monitor and access multiple servers from a single console simultaneously. And the first administrator can control, rest of administrators can view only. A single TR300IPK can control a server in BIOS level. When it connects with KVM it can control multiple servers.

Experience the convenience of the KVM over IP Switch - 1 Port, VGA, Up to 1920 x 1080@60Hz and order yours online today!

Product Features:

  • Support 1 individual local console
  • Support server with VGA port with USB keyboard and mouse
  • Support mouse synchronization mode-automatically synchronizes the local and remote mouse movements
  • Multiplatform support (Windows, Linux, Unix, Mac, Solaris (Sun), Redhat, Ubuntu
  • Supports a graphical interface for intuitive and convenient human-computer interaction
  • Adaptive 10 / 100 / 1000 Mbps network
  • WEB browser-based remote management
  • BIOS-level access
  • Resolution is up to 1920 x 1080@60Hz
  • Video quality and video tolerance can be adjusted to optimize data transfer speed, data transfer speed is up to 30 FPS
  • Full screen or scalable video display
  • Video sharing support
  • Support AES / DES / 3DES encryption
  • Support audit function-allows the administrator to audit the device through the system log and operation log
  • Configurable user and group permissions for server access and control
  • Support firmware upgrade

Connection Diagram:



Product Specifications:

Model TR300IPK

User
Local 1
Remote 1
Computer Connection 1



Connector

Console
Keyboard USB
Mouse USB
Screen VGA
Network 1x1000Mbps
USB2.0 1x USB TYPE B
1x USB TYPE A

Resolution
Local: 1920 x1080 @60Hz Remote: 1920 x1080 @60Hz



Remote
Remote Control KVM control (ActiveX)
Management Web
Security DES encrypted
Power Input DC12V
Power Consumption 5W
Temperature 0— 50 ℃
Storage Temperature -20—60 ℃
Humidity 0—80% RH, Non-condensing
Net Weight 1.1Kg
Measurement (W x D x H) 260mm× 116.6mm×44mm
Packing (W x D x H) 330mmx255mm×95mm
