Description
Product ID: TRL151KFH
Description
The IP KVM Matrix System is a solution that combines KFH Series KVM extenders (TRL151KFH), with the IP KVM Matrix System to extend, control, and monitor access to computers, across a Local Area Network(LAN), in a multitude of ways. The system lets you set up a matrix of remote KVM consoles that access computers across a LAN, with the flexibility to control and configure each connection.
The TRL151KFH extenders support flawless and lossless video compression quality with ultra-low latency, Latency as low as 16 milliseconds, and resolution up to 3840x2160@30Hz.
The USB2.0 transparent transmission technology supports USB devices like touch screens, USB sound cards, printers, and USB storage devices.Multiple USB ports in the rear allow you to connect several peripherals like a mouse, keyboard, monitor, printer and more!
The KVM extender consists of a transmitter and a receiver. The transmitter connects to a computer to deliver the computer’s data to the receiver to collectively provide console access from a remote or separate location. The computer can be accessed via a network or direct Ethernet cable connection from the remote console.
Experience the convenience of remote access over your computer system with our USB VGA IP KVM Matrix Extender via Cat5E or Cat6 or Cat7 or Optical Fiber Cable (mode is up to optical module) and order yours online today!
Product Features
- Uses one fiber optic cable to connect the transmitter and receiver units.
- VGA / USB2.0/Audio/Rs232 - IP KVM Matrix Extenders
- Flawless and lossless video compression quality with ultra-low latency(<1 frame/sec.)
- Supports standard resolutions from 640 x 480 to 3840x2160@30Hz.
- Graphical UI interface (Language in Chinese and English), which can realize human-computer interaction such as intuitive and convenient port switching
- Supports seamless, no black screen switching between PCs
- Supports USB2.0 transparent transmission with transfer rate up to 12MB/s
- Supports 1 channel RS232 asynchronous serial port transmission. RS-232 serial ports allow you to connect to a serial terminal for configuration and serial devices such as touchscreens and barcode scanners.
- Supports single-mode and multi-mode optical fiber transmission. The transmission distance depends on the type of optical module
- Supports redundant network backup (optical port & network port)
- Supports connection via Gigabit Ethernet port (RJ-45) or SFP port for failover.
- Supports screen lock.
- Supports one administrator account (Admin) and one User account.
- OSD (On Screen Display) on the Receiver configures Tx / Rx devices
- Seamless and fast switching
- Supports digital audio/ analog audio Hybrid Mode.
- Direct connection- via a CAT6 cable, you can also connect the transmitter to multiple receivers and vice versa.
- Connection via a Hub/switch - supports up to 40 units. Moreover, with the IP KVM Matrix Manager (DC-SG), it supports up to 9999 units(Tx & Rx).
- Remote login security.
- VGA connection, local USB loop out, remote USB ON/OFF, remote powering on/off (TRL151KFH-TX / TRL151KFH-RX).
- VGA OUT loopback port on Transmitter(Tx).
- Supports CAT5e/6/7 transmission. The longest point-to-point extension distance is up to 120m.
- Push & Get - shares content instantly to/from a single Rx or video wall with just one click.
Connection Diagram
Single transmitter（TX）connected to a single receiver (RX)
Connection Diagram of TRL151KFH
Specifications
| Specifications | TRL151KFH_TX | TRL151KFH_RX | |
| Connections | HDMI input | 1 | N/A |
| HDMI output | N/A | 1 | |
| VGA in | 1 | N/A | |
| VGA out | N/A | 1 | |
| Power | 12V | 12V | |
| LAN port | RJ45 x 1 | RJ45 x 1 | |
| Optical Module | SFP+ x 1 | SFP+ x 1 | |
| Microphone | 3.5MM Stereo Jack (Green) | 3.5MM Stereo Jack (Pink) | |
| Speaker | 3.5MM Stereo Jack (Pink) | 3.5MM Stereo Jack (Green) | |
| Square USB | 1 | N/A | |
| USB 2.0 | USB x 2 | USB x 4 | |
| RS485 | 1 | 1 | |
| Resolution | 3840*2160@30Hz | ||
| Cable | CAT5e/6/7 Or Optical Fiber Cable (mode is up to optical module) | ||
| I/R Value | DC12V / 2A | ||
| Power consumption | 6W | ||
| Operating Temperature | 0-50℃ | ||
| Storage temperature | -20-60℃ | ||
| Humidity | 0—80% RH, non-condensing | ||
| Material | Metal | ||
| Net weight (kg) | 0.75 kg | ||
| Product dimension (W × D × H) | 180mm x 123.5 mm x 44mm | ||
| Package dimension (W × D × H) | 395 mm x 274 mm x 110mm | ||
